EP-NRV-E063 — Shaft-Input Aluminium Worm Gearbox with Tail Output Shaft
Technical Specifications — EP-NRV-E063
| Parameter | Value |
|---|---|
| Series | NRV-E (Solid Shaft Input, No Flange, Worm-Direction Tail Output Shaft) |
| Centre Distance | 063 mm |
| Reduction Ratios | 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100 |
| Rated Input Power | Up to 2.2 kW |
| Output Speed Range | 14 to 280 r/min (at 1400 r/min input) |
| Max Output Torque | 5,595 N·m |
| Input Configuration | Solid shaft input (no IEC flange) + worm-direction tail output shaft |
| Input Shaft | Solid keyed shaft input |
| Tail Output Shaft | Worm-direction (co-axial with worm shaft, opposite end) |
| Housing Material | Die-cast aluminium alloy |
| Worm Wheel Material | Phosphor bronze |
| Worm Shaft Material | 20CrMnTi alloy steel, case hardened, precision ground |
| Output Bore Diameter | 28 mm H7 with keyway |
| Lubrication | ISO VG 220 gear oil (factory filled) |
| Mounting Positions | B3, B6, B7, B8, V5, V6 |
| Protection Class | IP54 |
| Ambient Temperature | -10°C to +40°C |
NRV-E063 Performance Table (2.2 kW / 1400 r/min)
| Ratio (i) | Output Speed (r/min) | Output Torque (N·m) | Service Factor (fs) |
|---|---|---|---|
| 7.5 | 187 | 1,315 | 2.5 |
| 10 | 140 | 1,447 | 1.9 |
| 15 | 93 | 1,657 | 1.3 |
| 20 | 70 | 2,503 | 1.6 |
| 25 | 56 | 2,696 | 1.4 |
| 30 | 47 | 2,973 | 1.3 |
| 40 | 35 | 3,272 | 1.1 |
| 50 | 28 | 3,524 | 0.9 |
| 60 | 23 | 3,745 | 0.9 |
| 80 | 18 | 4,122 | 0.9 |
| 100 | 14 | 5,595 | 0.9 |
✅ Core Features & Unique Benefits
🔗 Worm-Direction Tail Output Shaft — The Key Differentiator
The defining feature of the NRV-E063 is its additional tail output shaft that extends in the same direction as the worm shaft axis. This second output enables simultaneous drive of two independent loads from a single gearbox — a primary application drive via the main output bore and a secondary auxiliary drive (encoder, tachometer, small pump, or fan) via the tail shaft.
🖼 Line Shaft + Master Encoder Reference
The NRV-E063 is the preferred solution for central-line-shaft packaging facilities where each station requires chain input for drive and a tail shaft encoder for PLC synchronisation.
◯ Same Torque as Standard NRV063
The NRV-E063 delivers identical maximum output torque (5,595 N·m) to the standard NRV063, confirming that the tail shaft adds zero performance penalty on the main output. The tail shaft is driven directly off the worm shaft end, not the output stage.
🅆 Encoder & Feedback Ready
The tail output shaft provides a direct connection point for rotary encoders, tachogenerators, and pulse generators that monitor worm shaft speed in closed-loop motion control systems, eliminating external encoder brackets and coupling hardware.
🚫 IP54 — Dual-Seal Integrity
Both the main output bore and the tail shaft exit are sealed with dual-contact lip seals, maintaining IP54 protection across all mounting orientations without oil weeping at either shaft interface.
🏭 Application Scenarios
🖼 Print Line Master Reference Shaft
NMRV-E063 worm gearbox where the tail shaft serves as the master reference speed shaft for a multi-section printing press, providing a clean encoder signal isolated from the print-roll mechanical loads.
🌿 Precision Agricultural Seeding
Medium-duty worm gear reducer with tail output shaft for precision agricultural seeding and fertiliser application equipment where GPS-linked controllers require accurate shaft speed feedback for variable-rate application.
⚙ Automation Line Synchronisation
Industrial worm gearmotor with tail shaft for central-line-shaft automation systems where the tail-mounted tachogenerator provides the supervisory controller with a line-speed reference signal.
💧 Water & Wastewater Monitoring
Corrosion-resistant NMRV-E worm gear reducer with tail output shaft for instrumented valve actuator drives in water treatment plants, where the tail shaft pulse counter confirms valve position remotely.
🔎 Selection Guide
Worked Example — Packaging Line Synchronisation
Required: NRV-E063 at i=40, chain-driven from 2.2 kW central shaft, tail shaft to PLC encoder. Output speed = 35 r/min, torque = 3,272 N·m. Tail shaft: 500 PPR encoder, 28 mm bore. ✅ NRV-E063-40 selected.
⚖ NRV-E063 vs Standard NRV063
| Feature | EP-NRV-E063 (with Tail Shaft) | EP-NRV063 (Standard) |
|---|---|---|
| Tail Output Shaft | ✅ Yes — worm-direction | No |
| Encoder / Feedback Mounting | Direct on tail shaft | Requires external bracket |
| Dual-Load Drive | Yes — main + tail | No — single output only |
| Main Output Torque | 5,595 N·m | 5,595 N·m |
| Housing Dimensions | Slightly longer (tail shaft protrusion) | Standard length |
| Shaft Input | Yes — solid keyed shaft | Yes — solid keyed shaft |
NRV-E063 Main Output Shaft Dimensions
| G1 (mm) | K1 (mm) | L/DZ (mm) | L1/SZ (mm) | b2 (mm) | d h6 (mm) | Keyway |
|---|---|---|---|---|---|---|
| 110 | 109 | 173 | 219 | 8 | 28 | M10 |
❓ Frequently Asked Questions
What is the tail output shaft on the EP-NRV-E063 and how is it different from the main output?
The tail shaft on the NRV-E063 exits the housing in the worm-direction axis (opposite end of the worm shaft), while the main output bore is perpendicular (90 degrees) to the worm axis. The tail shaft is driven off the worm shaft end and is used for encoder mounting, tachometer connection, or light auxiliary drive, while the main output delivers the full 5,595 N·m load torque.
Does the tail shaft reduce the main output torque of the NRV-E063?
No. The tail shaft draws only the small torque needed for its connected device. The main output retains the full 5,595 N·m rating, identical to the standard NRV063.
What is the input shaft specification for the NRV-E063?
The NRV-E063 has a solid keyed input shaft (no IEC flange). The shaft diameter matches the equivalent NMRV063 bore input diameter. It accepts chain sprockets, belt pulleys, and rigid couplings. A bilateral (double-ended) input shaft is standard; single-end configuration available on request.
What encoder types can be mounted on the NRV-E063 tail shaft?
Any standard keyed rotary encoder with the matching bore diameter can be mounted on the NRV-E063 tail shaft: incremental (5V–24V, 100–10,000 PPR), SSI absolute, or resolver-type. Confirm the encoder bore size and keyway before ordering. The tail shaft key dimensions match the catalogue DZ shaft specification for NMRV-E063.
Can the NRV-E063 be used for closed-loop speed control in a chain-driven system?
Yes. The NRV-E063 is the ideal solution for chain-driven systems requiring closed-loop speed feedback. The chain drives the solid input shaft; the main output drives the load; and the tail shaft mounts an encoder that feeds speed/position data back to the controller. This eliminates the need for a separate encoder mounting bracket or a second independent encoder drive arrangement.
⭐ Customer Reviews
★★★★★
“Eight NRV-E063 units drive our packaging hall central-line-shaft chain conveyors. The tail-shaft encoders synchronise all eight lines via our PLC. Production throughput increased 12% after synchronisation was implemented.”
Marcus L. — Maintenance Engineer, Packaging Plant 🇦🇺 Australia (NSW)
★★★★★
“We use NRV-E063 on our grain cleaning machine chain drive. The tail-shaft rotation sensor confirms grain flow and triggers an alarm if the screen stops. The system has prevented three cleaning machine jams from escalating to equipment damage.”
Peter D. — Farm Engineer, Cropping Operation 🇦🇺 Australia (VIC)
★★★★☆
“The NRV-E063 drives our textile weaving machine chain take-up. The tail-shaft tachometer feeds our tension control loop and fabric tension consistency has improved dramatically compared to our previous open-loop chain drive.”
Elif T. — Production Engineer, Textile Manufacturer 🇹🇷 Turkey
⚙ Accessories & Compatible Products
⚡ IEC Motors (B5/B14)
Standard AC motors with matching IEC flange. VFD inverter-duty versions available for variable-speed control.
🔗 Output Shaft Kits
Single solid (DZ), double-ended (SZ), output flange (F), hollow flange (FL) — all H7/h6 tolerance with standard keyways.
🔨 Torque Arms & Brackets
Steel torque reaction arms for shaft-mount configurations; foot-mounting plates for B3/B6 orientations.
🔒 Seal & Breather Kits
Replacement lip-seal kits, vented breather plugs, and magnetic drain plugs for extended service intervals.
Get a Quote for EP-NRV-E063
Our engineers will confirm the input shaft key dimensions, ratio, and PLC encoder specification for your line-shaft or chain-driven application.
The EP-NRV-E063 aluminium worm gearbox combines a solid shaft input (no IEC flange) with an additional worm-direction tail output shaft. Centre distance 063 mm, ratios 5 to 100, input power up to 2.2 kW, max output torque 5,595 N·m. The tail shaft enables simultaneous encoder feedback, safety interlock monitoring, or auxiliary drive — the ideal instrumented shaft-input worm gearbox for chain-driven closed-loop agricultural, industrial, and mining drive systems.
